i5 4690k Overclock: Know Your Processor’s Limits and How to Extend It

How far you can overclock your i k

An i5 4690K overclock can help you unlock the processor’s full potential. Even though the 4690K is good enough on its own with its above-average effective speed of 103, sometimes you just need to overclock it.

Overclocking an i k

For example when playing the latest CPU-intensive game like Civilization 5 or Far Cry 5 or doing some demanding task like 3D rendering or video encoding.

Read the article to find out how.

Overclocking an i5 4690K: The Process Explained

It is possible to overclock an i5 4690K, provided that it’s unlocked and from the K series. You can overclock the Intel Core i5 4690K and take it up from its stock 3.9GHz maximum speed (with the turbo) to up to an overclocked speed of up to 4.4 GHz or even more than that, depending on your cooling system. If you go beyond that, your system might become unstable, crash, and display a blue error screen.

As per different tests and reports, overclocking can give you a maximum gain of up to 8.5% in terms of performance.

Make sure you don’t confuse the i5 4690K with the i5 4690. The latter is from the non-k series, which shouldn’t be overclocked. Processors with K in their name are specifically designed for overclocking. These include processors from Haswell, Sandy Bridge, and Ivy Bridge.

– What Do You Need to Overclock the i5 4690K?

When it comes to overclocking the CPU, you need to consider the following:

  • Load Line Calibration or LLC
  • VCore of the CPU voltage
  • Latest BIOS update
  • Any power-saving setting that you might have enabled
  • Updated chipset driver

Experts recommend overclocking only through the BIOS and not some i5-4690K overclock software, especially for beginners. Nearly all motherboards come with a UEFI/BIOS along with comprehensive options for overclocking, allowing users to get the maximum performance from the setup.

– The Maximum Limit of i5 4690K Overclocks

The maximum limit for each chip varies, so you’ll have to experiment a bit to really understand how far you can overclock your i5 4690K. While some chips can run on 4.4 GHz without any problems, others fail to cross even 4.3 GHz.

Generally, an i5 4690K can support overclocking up to 4.5GHz on all its core and sometimes even more than that if you’re lucky. The safest and simplest way to test your i5 4690K to its limit is to disable the turbo boost in BIOS and increase the CPU’s multiplier slowly. By default, the multiplier should be on 35 or auto.

– Best Overclock Settings

The overclock settings will differ from one chip to another, which is why you’ll have to experiment a bit here, too.

As a good starting point, you can make the following changes:

  • VCCIN to 1.85V (depending on your setup and cooling system)
  • Multiplier to 44
  • V core to 1.2

And then try to boot the processor at 4.4 GHz. If it fails to boot, slowly reduce the multiplier and then try booting again. Once you find a speed that you can boot the chip at, you will have to test for stability. To do so, you need to adjust the clock speed bit by bit and continue testing the stability until you find a speed you’re happy with.

If 10 minutes of stress testing your CPU at these settings shows stable results, you can increase the V core and the multiplier. In most cases, a 1.2 Vcore at 4.4 GHz tends to fail the stress test after a couple of hours. But you might be able to stress-test the processor at 1.25V at 4.5 GHz for up to 7 hours before the test fails.

You also don’t need to worry about i5 4690K hyperthreading affecting the stability. This is because the processor doesn’t allow for hyperthreading; it just has four cores/threads.

– The Safest Overclock for i5 4690K?

When it comes to overclocking, there’s no safe overclocking for a certain chip. Each chip is different, but most people can get around 4.2 to 4.4 GHz with a decent motherboard and cooler.

The Safest Overclock for i5 4690K

The safest way is to continuously test the system’s stability before increasing the multiplier. In case the system becomes unstable, you can either try to stabilize it by providing more voltage to the processor, or you can go back to the latest stable clock.

You also need to be careful of the system temperature during load. If it gets too hot, decrease both the voltage and the multiplier. As a general rule, the CPU temperature should be less than 75C for daily use. It’s advisable that you change the thermal paste before overclocking your CPU if you haven’t done so within the last year.

So to sum it up, a safe overclock is the maximum speed you can take the processor to without providing too much voltage or without it overheating.

– Overclock Limits for i5 4690K

Monitoring the temperature is the easiest way to know if you’ve reached overclocking limits. As the overclock increases, so does the temperature. So, how far you can go with overclocking depends on how good of a cooling solution you have.

If you use the default fan that comes with the CPU package, you won’t get a lot of room to overclock. In fact, some coolers fail to cool the CPU enough, even at its default speed. Meanwhile, if you have a liquid cooling setup for your CPU, you might be able to push your i5 4690K more and get better overclocking.

– What Is the i5 4690K Overclock Benchmark?

If you’ve ever done an i5 4670K overclock, you know what to expect from overclocking its successor, the 4690K. The two have similar architecture, and as such, there’s not a big increase in performance.

But if you can get all four cores to overclock to nearly 4.5 GHz, you can expect to see a 20% performance increase in different CPU benchmarks. This means you can get a considerable boost not just for productivity tasks but for gaming, too.

Different i5-4690K benchmark tests suggest an average bench of 77.7% and above-average consistency, which means that the processor performs quite consistently under different real-world conditions.


– Why Would You Want to Overclock the i5 4690K?

Despite the lack of integrated graphics, the 4-thread 4-core 3.5 GHz processor is quite powerful and can handle very demanding games well.

Why would you want to overclock the i k

It also has excellent dual- and single-core performance, which is 12% better than the average performance of similar processors. Plus, Intel’s auto-overclocking feature (turbo boost), increases its clock speed to 3.9GHz, allowing you to achieve higher frequencies.

But it can sometimes experience a bottleneck, especially with CPU-intensive tasks. In such cases, overclocking can help.

– What Performance Gains Can You Get By Overclocking an i5 5690K?

You can notice a big difference in terms of performance when you’re able to utilize the CPU to its maximum potentials, such as when using mathematical software like Wolfram Mathematica or MATLAB, rendering FHD videos, or playing games.

However, if you’re just a basic user, you won’t really notice a lot of difference. In fact, if your CPU use is limited to very basic tasks, you don’t even need to overclock your processor.

Note that your CPU usage doesn’t need to be at 100% if you want to get a performance gain from overclocking your CPU. The only time you can see your CPU usage touch 100% is when all the threads and cores are occupied with some tasks. Overclocking can help if one or two cores are heavily tasked, but this won’t show 100% CPU usage in a graph.

– How Is the i5 4690K Overclock vs Stock Performance for Gaming?

The difference in the stock and overclock performance of the i5 4690K is quite noticeable, especially when it comes to gaming. An overclocked 4690K provides a better average FPS and low 1% FPS than a stock 3.9GHz when tested on a number of games, including CS:GO, Rainbow Siege Six, Overwatch, Destiny 2, Resident Evil 2, Modern Warfare, Battlefield V, Far Cry, and Apex Legends.

Programs that scale linearly to the processor’s clock will also notice a great difference.


We’ve covered nearly everything there is to know about overclocking the i5 4690K. Let’s quickly sum up all that we’ve talked about:

  • It is possible to overclock the i5 4690K (not to be confused with the i5 4690) and take it up from its stock clock speed of 3.5 GHz to up to 4.6GHz, provided that you have a good cooling system in place.
  • The highest that you can overclock the i5 4690K varies from chip to chip. You’ll have to experiment with your chip and find a clock speed at which your system stays stable.
  • Overclocking this processor can provide better gaming performance than the stock speed, especially when it comes to the average FPS and the low 1% FPS. This applies to most CPU-intensive games like CS:GO, Modern Warfare, Battlefield V, and Far Cry.

Just make sure you keep a close eye on your PC’s temperature and stress test it for stability to find the right overclock settings and not harm it.
