Link Your TV to a Receiver Without HDMI
Link Your TV to a Receiver Without HDMI

Mastering how to connect TV to receiver without HDMI requires deep knowledge of different audio and video cords.

Connect TV to Receiver Without HDMI Like an Expert

Note that the standard way of connecting your TV to a receiver is usually via an HDMI cable, but in the absence of an HDMI jack, you will need an alternative. Read this post to learn how to link your TV to the receiver without an HDMI cord.

How to Connect TV to Receiver Without HDMI in 4 Steps

To link your TV to a receiver without HDMI, you can use an RCA cable. To do so, power your TV, plug in the wires in their rightful ports, and change the TV’s default speaker to external. Now, test your connection.

Here is how to connect receiver to TV using RCA cables:

– Step One

Since there are many other RCAs, choose the one you want to use. The standard cables are:

  • Basic RCA Audio Cords: These audio cords feature a red and white connector hence the name red and white RCA cables. It transmits only Audio and connects your TV to the receiver via RCA jacks. So match up white and red wires o white and red jacks.
  • Composite Video Cords: These cables support video and Audio from one component to another. The cable features white, red, and yellow connections. It is called composite because you only need the yellow cable for video.
  • Component Video Cables: These cables use many connector channels to transmit video signals instead of single composite cords. It uses green, blue, and red cables for video transmission. You can buy a composite with three cables or one with 5 RCA components, including two audio connectors.

– Step Two

Switch on your receiver and TV. First, you must plug the TV and the receiver into a power source. Once powered on, plug the RCA audio cables into the receiver and the TV.

Since you will be connecting your TV, use the Composite Video Cables. Usually, the ports are labeled Audio, Component, or Composite.

Use the colors to guide you as you plug the cables – the colors of the wires should match the color of the port.

– Step Three

Change your television’s default speaker to the external speaker you have connected. The process of changing varies with your TV model. However, the main steps require you to access your TV’s sound section main settings.

If you have a smart television, follow the steps below:

  • Go to the TV’s settings and select Sound Settings
  • Press Sound Output. This option takes you to the TV speaker by default
  • Choose the speaker you want to use and Press Close.

– Step Four

Test your setup to see if it works. Start by turning the volume up and see if there is some sound. If there is sound/music, the cable works fine. If not, check the connection and try again.



How to Link Your TV to a Receiver Without HDMI and RCA Cable?

You can link your TV to a receiver without HDMI and RCA cables by using digital coaxial audio cables. If you cannot get hands-on with these cables, you can also opt for an optical audio cable. On top of that, an HDMI converter can also be used for this purpose.

– Digital Coaxial Audio Cables

The digital coaxial audio cords send digitized digital signals from your TV to a receiver.

Connect with Digital Coaxial Audio Cables

This cable runs from the TV through the back of the receiver. Here is how to use a coaxial cable:

  • Insert the cable barrels at the end at the back of the TV. Be sure to plug it into the Audio Output jack on your TV.
  • Insert the opposite end of the cord into the corresponding jacks on the receiver.
  • Switch on the TV, set the output to “Audio out,” and choose coaxial Audio from the receiver.

Your Audio will play once your connection is made. If not, check your connection.

– Optical Audio Cable

Optical Audio cords carry Audio from your TV to the receiver. So, if you want to transmit audio signals, this is the cable. Here is how to connect TV to stereo receiver using Optical Audio wires.

Get your optical cable and connect it to the Optical Digital IN port on the receiver or Optical Digital OUT port.

Turn on the TV. For those with smart TV, how to connect smart TV to receiver without HDMI:

  • Launch the Settings screen. Press the Quick Settings button on your remote control and go to Settings.
  • Select the HOME button on your remote control and select Settings.
  • Depending on your TV menu options, you can go to Display & Sound and go to Audio output. Select Speakers and go to the Audio system.
  • Alternatively, select Sound, go to speakers and select Audio system.
  • Set your TV sound to the desired setting, Variable or Fixed. However, some TVs do not have this setting while on Android TV. You can access this setting via Audio out (Fixed) and adjust the volume on the receiver.

If you choose Audio out (Fixed), you will get Audio from your TV and a sound output device.

– HDMI Converter

You can also use the HDMI converter to link your TV to a receiver. This option does not require an HDMI. Note that the converter lets you link your old analog source to a modern television.

Typically, it converts analog audio from a source to a digital signal, then transmitted via HDMI. Typically, the HDMI (High Definition Multimedia Interface) converter links non-HDMI sources to HDMI displays. So, here is how to connect old receiver to new TV:

  • Get the correct HDMI converter, for instance, the Philips DisplayPort-to-HDMI adapter or insignia RCA to HDMI converter ns-hz330. The choice will depend on the ports on your receiver. In this case, our converter allows an HDMI to HDMI cord on one side and an RCA to RCA cord on the opposite side.
  • Connect one end of your High Definition Multimedia Interface cable to the HDMI converter and the opposite end to the HDMI port on your TV. Use any ports if your TV has more than one HDMI port. Ensure that your television input settings have selected the correct High Definition Multimedia Interface port.
  • Plug your travel charger into the High Definition Multimedia Interface converter, and plug the charger into an approved power socket.
  • Connect the RCA cord to the corresponding port on your receiver.

Typically, the suitable converter will let you flawlessly convert your digital audio to an analog signal, provided you have the correct cables for the two devices—converters such as the onn. HDMI to composite AV adapters effectively give instant and flawless connections.

How to Link Your TV to Receiver With Hdmi Without ARC

You can connect your TV to a receiver via Bluetooth if your receiver has HDMI without ARC (Audio Return Channel). But ensure that your TV has a transmitter. Pair your TV with the receiver and enjoy high-fidelity music. You can also use a digital optical cable or an analog connection.

While most modern systems have HDMI eARC, the lack of primary ARC doesn’t mean you won’t get the best surround sound. Here is how to connect TV to receiver with HDMI without arc:

– Bluetooth Connection

This is a viable option if you have a smart television. A Bluetooth adapter for TV allows your television to stream sound to your wireless speakers or headphones, even if the TV does not support the feature.

But you must buy the correct Transmitter receiver. Most transmitters support Bluetooth 5.0 and 3.5MM AUX Jack Stereo USB Adapter Wireless Dongle. The wireless adapter enables your AV Receiver, TV, Radio, and other home audio devices to stream Audio to your wireless connection.

– Analog Connection

Most TVs and receivers support the 3.5 audio and at least one RCA output. So this makes it easy to connect your TV to your receiver through an RCA/AUX cable.

RCA_AUX cable makes it easy to connect your TV

As stated earlier, these cables are normally white and red, transmitting only stereo Audio signals. You will have to plug one cable end into the corresponding port on the receiver and the opposite end into the corresponding port on the TV.

How to Link Your Receiver to TV and Cable Box Correctly

You can link your receiver to a TV and cable box correctly by ensuring that you have the required cables for a successful connection. After that, you have to plug the coaxial cable from the socket on your wall into the cable box.

Here is how to connect receiver to TV and cable box:

– Step One

Ensure that you have the required cables for a successful connection. You will need HDMI, composite cables, composite Audio, and composite A/V cables.

– Step Two

Plug the coaxial cable from the wall socket into the RF IN jack at the back of the cable box. Connect the HDMI cord to the HDMI OUT jack at the back of the cable box.

Plug the opposite end of the HDMI cord into the HDMI jack at the back of your TV. No further requirements if your TV has an HDMI jack.

Otherwise, if it has a DVI jack proceed to the next step.

– Step Three

Plug the opposite end of the HDMI cord into the HDMI jack on the HDMI-to-DVI adapter and plug the HDMI-to-DVI adapter into the DVI IN jack on the back of your television.

– Step Four

Insert the Composite audio cord HDMI OUT into the AUDIO OUT jack on your cable box. Plug the opposite end of the cable to the AUDIO IN jack next to the DVI jack on the back of the television.

Conclusion

This post deeply explains how you can connect your TV to a receiver without HDMI cables.

Here are key points:

  • You will need an HDMI adapter, digital or analog, and optical cables to complete the connection.
  • For Sound receivers, you may use Bluetooth receivers for the perfect surround sound effects.
  • Without HDMI ARC, you will need more cable between your TV and sound receiver, such as external home theater systems.
  • You must plug the HDMI cable into the TV’s HDMI IN on one side and HDMI OUT on the speaker to get an HDMI connection.

If you do not have an HDMI cord, use the above methods to link your TV to your favorite receiver.
